XT-PS03 Triple Beam Polarized 3D System
Core Highlights
Triple Beam 3D System: Groundbreaking three-optical-channel architecture for maximum brightness.
Ultra-High Light Efficiency 3D: Achieves an industry-leading 32% ± 2% efficiency.
High-Brightness Cinema 3D: Specifically engineered for Giant Screen (PLF) theaters.
Technical Specifications:
Model: XT-PS03 (Flagship Triple Beam)
Optical Principle: Triple Beam Polarized / Three Optical Channel
Light Efficiency: 32% ± 2% (Industry Peak)
Ghost Rate: < 1% (Ultra-low crosstalk)
Response Time: < 150us (Micro-second high-speed switching)
Frame Rate Capacity: Supports > 480Hz (Perfect for 4K/HFR)
2D/3D Conversion: Fully Automatic (Supports Cinema TMS)
Light Transmittance: 82% ± 2.5%
Maximum Screen Size: Optimized for screens up to 25 meters width
Screen Support: Silver Screen (Gain 2.0 - 3.0 recommended)
Polarization Contrast: > 150:1 (On metal screen)
Maximum Projector Lux: Supports up to 80,000 Lux
Compatibility & Installation
Supported Projector Brands: Fully compatible with Christie, Barco, and NEC high-lumen digital cinema projectors.
Sync Interface: Standard DB37 / DB15 cinema synchronization ports.
Operating Conditions: 0-60°C; robust design for 24/7 commercial cinema environments.
